Page 78 - Product Catalog By Zika Welding

78

WELDING & CUTTING MACHINE

STICK WELDERS

MINI-160

PORTABLE, LIGHTWEIGHT AND PROFESSIONAL ADVANTAGES OF THE MACHINE

DESCRIPTION AND APPLICATION • Lightweight and convenient
to carry, Rigidity, durability and
1. A single phase, easy to carry welding machine that comes in a particularly durable warranty
rigid carrying case, combining maximum convenience in carrying.
• A rigid, IP21 rated dustproof case
2. The case protects the welding machine so that the machine is protected from for use in outdoor conditions.
dust and impact during storage as well as being optimally stored.
• A ventilation system with a
unique structure that combines
3. The welding machine is intended for operation with a 16 ampere electrical fuse.
a strong fan with a very large
passive cooling unit.
4. The welding machine provides a great solution for welders who perform various
welding jobs using electrodes of up to 3.25 mm diameter in the maintenance and • Professional and technical
general joining field. consultation of welding experts.
5. The welding machine is intended for intensive welding work at a maximum • 12 months of comprehensive
current of 166 amps. warranty from Zika Group Ltd.
6. Full protection from overloads.

7. Also works on an 8KVA generator output.

SET SPECIFICATION

• Mini-160 welding machine.
• Lined rigid case for protecting the
machine.
• 16 mm cross section welding cable.
2
• 300 amp electrode holder
2
DC 1 50 60 • 16 mm section grounding cable.
• Grounding connection handle.
one
phase Hz
• 2 meter standard power cable and
Israeli Standard approved type plug.
TECHNICAL SPECIFICATION

Input voltage Required Current range Open circuit Currency as 60% Weight Works with Dimensions - mm Case
V fuse A A voltage V efficiency A Kg generator (l/w/h)

230 16 30-166 65 166 5.5 + 203/132/290 +
