82

STICK WELDERS

I-DC-500

THREE PHASE 500-AMPERE ADVANTAGES OF THE MACHINE
INDUSTRIAL WELDING MACHINE

• ARC FORCE selector - gives a great advantage in integrating
convenience and increased penetration power during the
DESCRIPTION AND APPLICATION welding work. This selector is very important for performing
pipe welding work (Z610) and is an advantage in performing
1. A powerful IGBT technology industrial welding machine. welding work by providing significant additional penetration
force during welding throughout the entire performance of the
2. A three phase industrial welding machine for continuous, welding operation.
intensive work for all types of welding and cutting using • Digital display for convenient, precise adjustment of
electrodes. current- A clear control display that provides for precision
3. A high power industrial welder designed for welding and control of the welding current and deep penetration.
cutting jobs in the fields of construction, piping, • Very high efficiency of more than 60% at 40 °C
maintenance and general welding requiring continuous, Celsius, allowing for continuous, intensive work under
intensive welding work using electrodes of up to 6 mm high load conditions.
diameter • A cooling system with triple protection, against water,
wind and dust.
• Ability to work at a voltage of 320 to 450 volts.
• HOT START - a property that allows for rapid, easy
ignition of electrodes, which is a major advantage in
working with the cellulose type electrodes used for pipe
welding (Z-610).
• A rigid, IP21 rated dustproof case for use in outdoor
conditions.
• Optimum performance of work, even with unstable
electrical grids.

• Open phase, low voltage, excess voltage / current and
overheating protection.
• Has a unique structure that combines a strong fan with
a very large passive cooling unit, with triple protection.

• Suitable for pipe welding.
• Professional and technical consultation of welding experts.
• 12 months of comprehensive warranty from Zika Group Ltd.

SET SPECIFICATION
• I-DC 500 welding machine.
• 50 mm cross section welding and grounding cables.
2
• 500 ampere electrode holder and grounding connection handle.
DC 3 50 60 • Standard power cable and Israeli Standard approved
three 3-phase type plug.
phase Hz
• Optional remote control for remote operation and welding
power adjustment.

TECHNICAL SPECIFICATION

Input voltage Required fuse A Current range Open circuit voltage Currency as 60% Weight Works with Dimensions - mm
V A V efficiency A Kg generator (l/w/h)
380 40*3 40-500 80 500 40 + 437/313/760
