Z-Ni B Specifications: Specifications: Z-Ni-182
AWS: A5.11 E NiMo-1 AWS: A5.11 E NiCrFe 3
EN ISO: 1736 E L-NiMo 29 EN ISO: 14172 E Ni 6182 (NiCr15Fe6Mn)
Description and Applications: Description and Applications:
• Basic coated thick electrode for depositing NiMo-1 alloy • Synthetic basic coated NiCr electrode
and welding NiMo alloys • For welding Ni-base alloys, claddings and
• Can be used at very high temperatures in reducing dissimilar metals
gases environment • High creep resistant and high resistance to embrittlement
• Excellent resistance to acetic, phosphoric, sulphuric
and hydrochloric acids Typical all weld metal composition [wt%]
C Mn Si Cr Ni Nb Fe
Typical all weld metal composition [wt%]
0.02 7.5 0.40 13.8 Bal. 1.8 4.4
C Mn Si Fe Mo V Ni
Typical all weld metal mechanical properties
0.05 0.60 0.60 5.0 27.00 0.25 Bal.
Rm [MPa] Rp 0.2 [MPa] A5 [%] Impact [ISO-V]
Typical all weld metal mechanical properties
600-660 380 32 80J@-196°C
Rm [MPa] Rp 0.2 [MPa] A5 [%] Impact [ISO-V]
Welding position
700 500 26 -
Welding position
ASME: 1G 2F 2G 3G 4G
ISO 6947 PA PB PC PF PE
ASME: 1G 2F 2G 3G Materials to be welded Current
ISO 6947 PA PB PC PF )= +(
ASTM UNS DIN W.Nr
Materials to be welded Alloy 600 N06600 NiCr15Fe 2.4640 Re-drying
ASTM UNS DIN W.Nr Alloy 601 N06601 NiCr23Fe 2.4851 2h/250ºC
Alloy B2 N10665 NiMo29 2.4616 Alloy 800 N08800 X10 NiCrAlTi32 20 1.4876
Current Alloy 800H N08810 X10NiCrAlTi32 20 1.4958
)= +( ~ Uo : 70v Alloy 75 N06075 NiCr20Ti 2.4951
Alloy 80A N07080 NiCr20TiAl 2.4952
Re-drying Alloy 90 N07090 NiCr20Co18Ti 2.4969
2h/250ºC
Alloy 9% Ni K81340 X8 Ni9 1.5662

Dia Length Current Weight Weight
in mm in mm )amps( kg/100 pcs packet )kg( carton )kg(
Dia Length Current Weight Weight
in mm in mm )amps( kg/100 pcs packet )kg( carton )kg( 3/32 2.5 14 350 75-100 2.6 2.0 12.0
3/32 2.5 14 350 90-110 3.6 2.0/2.5 12.0/15.0 1/8 3.25 14 350 100-140 4.6 2.0 12.0
1/8 3.25 14 350 130-150 6.3 2.0/2.5 12.0/15.0 5/32 4.0 14 350 140-180 7.0 2.0 12.0
5/32 4.0 14 350 180-200 9.3 2.0/2.5 12.0/15.0 3/16 5.0 14 350 170-210 10.0 2.0 12.0
